Auto Automatic Timed Electronic Drain Valve For Air Compressor

Auto Automatic Timed Electronic Drain Valve for Air Compressor Water Tank 1/2'' Welcome to Zishuobusiness 🌹 110v 1/2" Electronic Timed 2 Way Air Compressor Gas Tank Auto Drain Valve +Cable   Specification:

Easy to Install, Fully Automatic Operation

Power Cable with 3 Pin Us Plug.

Equipped with a Ball Valve Filter, Split with Drain Valve, an L-shaped Structure

Voltage: Ac110v 50hz

Voltage Range: 10%

Time Interval ( off ): 0.5--45 Minutes (Adjustable)

Discharge Time ( on ): 0.5--10 Seconds (Adjustable)

Manual Test Button: Yes( Micro Switch )

The Current Consumption: Max 4ma

Protection Grade: Ip65

Shell Material: Flame Retardant Abs Plastic

Indicator Lamp: Led Indicating Power on / off

Type: Two-way Direct-acting Valve

Flow Aperture: 5 Mm

In / out Port Size: 1/2"

Maximum Working Pressure: 1.6mpa

Maximum Temperature: 90 °C

Valve Material: Forging Brass

Installation: 1. Clean the Compressed Air System Before Installing 2. Attention to the Direction of the Arrow When the Valve Body; Outlet Do Not Use the Impact of the Hose Does Not Impact 3. the Supply Voltage Must Be the Same As the Drain Valve Voltage; When Using Dc, the Positive Pole Must Be Connected to the Connector "1" 4. the Factory Has Been Connected to the Cable Drain Valve, Fade for the Fire Line L, Blue for the Zero Line N, Yellow and Green Color for the Safe Ground Gnd 5. Always Tighten the Long Screws on the Terminal Box to Prevent the Water from Burning   Timer Setting: Left Knob to Set the Discharge Time, the Right Knob to Set the Interval Time; the First Discharge Time of 2s, the Interval Time Is 20min, and Then Need to Be Further Adjusted

Package Contents:

1 * Drain Valve with Power Cable



Notes：

The controller of this product is not waterproof, so it is not recommended to use it outdoors in the open weather.
